PTFE Bearing Slide

Kaxite Sealing's PTFE Bearing Slide is a high-performance linear motion solution, ideal for industrial and DIY applications. Crafted from durable PTFE, it ensures smooth, low-friction movement, reducing wear and enhancing precision. Perfect for engineers, hobbyists, and manufacturers, it transforms heavy-duty tasks into effortless operations, solving common sticking and noise issues. With its superior design and reliability, this slide outperforms competitors by offering longevity and quiet efficiency. Elevate your projects with Kaxite Sealing – experience seamless performance today!

Send Inquiry

Product Description

[ Features ]

PTFE bearing slide is made from high strength PTFE suspension resin by methods of moulding, sintering and finalizing the design to various sizes. Different fillings can be used to achieve special demands. It can also be adhered to rubber and metal with one side etched.
PTFE has very low coefficient of friction, it is anticorrosive and not aging, can be widely used in temperature from -180

to +260

[ Main properties ]

Properties	Unit	Result
Apparent density	g/cm³	2.10-2.25
Tensile strength (min)	MPa	30
Ultimate elongation (min)	%	250

[ Specifications ]

Round Type
Diameter(mm)	Thickness (mm)	Diameter(mm)	Thickness (mm)	Diameter(mm)	Thickness (mm)
Φ140	6-8	Φ240	6-8	Φ415	6-8
Φ150	6-8	Φ260	6-8	Φ636	6-8
Φ160	6-8	Φ300	6-8	Φ740	6-8
Φ180	6-8	Φ320	6-8	Φ852	6-8
Φ210	6-8	Φ340	6-8
