In the demanding world of industrial sealing, the quality of braided packing is paramount. This quality is directly determined by the precision, reliability, and sophistication of the machinery that produces it. For over two decades, Kaxite Sealing has been at the forefront of designing and manufacturing high-performance braiding machinery that sets the global benchmark. Our Machines For Braiding Packing are not just equipment; they are engineered solutions built to deliver consistent, high-density, and perfectly braided sealing products for the most challenging applications across oil & gas, chemical processing, power generation, and marine industries.
We understand that your production line's efficiency and output quality depend on robust machinery. Every Kaxite Sealing braiding machine incorporates decades of field expertise, resulting in a blend of rugged durability and advanced control systems. From traditional maypole braiders to sophisticated high-speed computer-controlled systems for complex patterns, we provide the technology to manufacture packing that meets exacting specifications for temperature, pressure, and chemical resistance.
Kaxite Sealing offers a comprehensive range of braiding machines, categorized by carrier count, braid type, and level of automation. Below are the detailed specifications for our flagship series.
| Feature | KX-BM-HP-A Model | KX-BM-HP-S Model |
|---|---|---|
| Primary Function | Fully Automated Square Braiding | High-Speed Plaited (Diamond) & Complex Braid Patterns |
| Max Carriers | 72 | 48 (with pattern control per carrier group) |
| Core Integration | Automatic core insertion (wire, elastomer, filament) with tension feedback. | Optional core feed system. |
| Control System | Industrial PC with touchscreen HMI. Stores hundreds of braid recipes (diameter, PPI, density). | Advanced servo-motor control for individual or grouped carriers to create custom patterns. |
| Braiding Speed | Up to 80 rpm | Up to 100 rpm for plaited braids |
| Data Output | Production data logging (OEE, speed, length), Ethernet connectivity for Industry 4.0 integration. | Pattern programming via software, remote monitoring capability. |
| Key Advantage | Hands-off production of consistent, high-density packing with integrated core for gasket or valve stem packing. | Versatility to produce specialized packing styles (e.g., interlocked braids) for unique sealing challenges. |
| Parameter | Specification |
|---|---|
| Power Supply | 380-480V, 3 Phase, 50/60 Hz (Customizable for regional standards) |
| Installed Power | 5.5 kW to 15 kW (depending on model and size) |
| Noise Level | < 75 dB(A) at 1 meter (with standard enclosure) |
| Machine Footprint | Varies from 2.5m x 2.5m (16 carrier) to 5m x 4m (72 carrier automated system) |
| Weight | Approximately 1,500 kg to 6,000 kg |
| Operating Environment | Temperature: 5°C to 40°C; Humidity: <80% non-condensing |
| Safety Standards | CE Certified. Includes emergency stop, guarding, and electrical safety per ISO 13849. |
What is the main advantage of using a dedicated braiding machine for packing versus a generic textile braider?
Dedicated packing braiders, like those from Kaxite Sealing, are engineered for high-density, low-porosity braids required for sealing. They feature heavier construction to handle abrasive materials like carbon and aramid, precise tension control for consistent density, and are often configured for square braids. Generic textile braiders lack the torque, tension control, and durability for continuous production of industrial sealing materials.
What type of braided packing can I produce with your machines?
Our standard KX-BM series is optimized for classic square braid (also called woven braid) packing, which is the most common form for pump and valve packing. Our advanced KX-BM-HP-S model can produce plaited (diamond) braids and even more complex interlocked braid patterns, which offer different flexibility and density characteristics for specific applications.
How do I determine the right number of carriers (bobbins) for my needs?
The carrier count directly influences the packing's density, diameter range, and production speed. A higher carrier count (e.g., 48, 64) allows for producing larger diameter packing and/or denser braids from finer filaments. For smaller diameter, general-purpose packing, 16 or 24 carriers may suffice. Our technical team at Kaxite Sealing can analyze your target product specifications to recommend the optimal model.
What is the role of the take-up system, and why is tension control so critical?
The take-up system pulls the finished braid from the machine. Precise, adjustable tension is crucial because it determines the final Packing Density (often measured in Picks Per Inch - PPI). Insufficient tension results in a loose, low-density braid prone to leakage. Excessive tension can cause yarn breakage or deformation. Kaxite Sealing machines use motorized capstans with feedback control to maintain consistent tension, ensuring every meter of packing meets spec.
Can your machines handle incorporating a core material into the braid?
Yes, this is a key feature of our automated KX-BM-HP-A series. It can automatically insert and tension a core material (such as an Inconel wire for high-temperature packing, an elastomeric cord for enhanced sealing, or a graphite filament) during the braiding process. This creates a homogeneous, high-performance product in a single pass, eliminating a separate manufacturing step.
How automated are your machines? Can they operate unattended?
Our standard series requires an operator for loading yarn bobbins, monitoring, and doffing finished reels. Our High-Performance Automated (KX-BM-HP-A) series is designed for minimal intervention. With large-capacity creels, automatic core feed, and programmable length counters with cut-off, it can run extended batches with only periodic checks. Full "lights-out" operation would require integration with additional robotic material handling systems, which we can engineer as part of a complete line.
What kind of training and after-sales support does Kaxite Sealing provide?
We provide comprehensive support throughout the machine's lifecycle. This includes detailed installation supervision, on-site operational training for your technicians, and maintenance training. Our support package includes a detailed manual, access to a library of video tutorials, and remote diagnostic support. We maintain a global network of service engineers and stock critical spare parts to minimize downtime.
What is the typical lead time for a machine, and what infrastructure is required in our factory?
Lead times vary from 8 to 16 weeks depending on model complexity and customization. Your facility will need a stable, leveled concrete floor capable of supporting the machine's weight, appropriate 3-phase power connection, and adequate space for operation and material handling (yarn storage, finished goods). We provide detailed site preparation guidelines upon order confirmation.
How does Kaxite Sealing ensure the durability and longevity of its braiding machines?
Durability is engineered into every component. We use high-grade cast iron and steel for gearboxes and frames, precision-ground gears and cam tracks for smooth carrier movement, and industrial-grade bearings and electrical components. Our rigorous factory testing includes a 72-hour continuous run-in test under load before shipment. This commitment to heavy-duty construction ensures a machine that delivers high uptime and a long service life, providing an exceptional return on investment.
The industry's move towards higher-performance materials and more demanding sealing specifications requires machinery that is equally advanced. Kaxite Sealing continuously invests in R&D to integrate smarter controls, higher efficiency drives, and more versatile braiding capabilities. Whether you are establishing a new packing manufacturing line or upgrading outdated equipment, our machines provide the technological foundation to produce superior braided sealing products reliably and profitably. We partner with our clients to understand their specific challenges, ensuring the machinery solution we provide not only meets but exceeds their production goals.
